Case-based learning: management of complex regional pain syndrome with a transdermal unlicensed medication

This case study considers the use of unlicensed topical medications for chronic pain when commercial medications are unsuccessful.
Case-based learning: management of complex regional pain syndrome with a transdermal unlicensed medication

By the end of this article, you should be able to:


Complex regional pain syndrome (CRPS) is a chronic neuropathic pain condition, clinically characterised by persistent, severe and debilitating pain lasting over six months; some people with CRPS experience pain for many years​[1]​. In most cases, pain affects one limb only (e.g. arm, leg, hand or foot) but it may extend to other parts of the body​[1]​. The pain feels like a combination of burning, stabbing or stinging, and it may cause tingling and numbness. It is caused by specific stimulus, but it may be triggered spontaneously. The skin in the affected area is usually extremely sensitive; for example, a subtle touch or change in pressure applied to the affected area, or change in temperature, may trigger pain​[2]​.

There are two types of CRPS, distinguished based on the absence or presence of a lesion to a major nerve. In CRPS type 1 (CRPS-1), there are no demonstrable nerve lesions and this is the most common type of syndrome, with one US population-based study estimating a period prevalence of 20.57 per 100,000 person years​[3]​. In CRPS type 2 (CRPS-2), there is objective nerve damage, most commonly caused by severe trauma​[3–5]​. The pathophysiology of CRPS is still poorly understood and additional consideration is being given to the role of psychological factors​[2,6]​. Stress is a common trigger of flare-ups, and it has been demonstrated that there may be a link between CRPS and history of depression and/or post-traumatic stress disorder (PTSD). Evidence suggests that CRPS is more prevalent in women, with an estimated female to male ratio of 4:1, and that it can affect people of any age, including children​[3,7]​

People living with pain experience a significant impairment to their health-related quality of life (HRQL) and many national governments now recognise long-term pain, or chronic pain, as a public health priority​[8]​. Patients with neuropathic pain are more affected compared with other types of chronic pain​[9]​. Community and hospital pharmacists can play an important role in pain management by educating the patient about the importance of self-care, physical rehabilitation and psychological support. Additionally, pharmacists can monitor the patient’s compliance to pharmacological treatment, as well as the occurrence of any unwanted side effects​[10]​. When appropriate, pharmacists may contribute further to patient-centred care by focusing on the patient and their particular healthcare needs by suggesting alternative pharmacological treatments to the physician. The goal of the triad relationship (pharmacist-patient-physician) is to reduce pain, increase mobility and improve the patient’s overall HRQL​[10]​.

Case presentation

The patient is a female, aged 37 years, with a medical history of chronic fatigue syndrome, irregular sleep patterns, PTSD and moderate Raynaud’s phenomenon (a disorder that causes decreased blood flow to the fingers and toes). The patient was diagnosed with CRPS-1, with severe intractable pain specifically centred around the left knee. The pain was triggered by various factors, including an ambient temperature lower than 32°C, subtle air movement across her skin and any noise stimuli higher than soft sounds. This extreme sensitivity is known as allodynia and it is a common presentation in CRPS, according to the variable criteria and guidelines for the differential diagnosis of CRPS​[1,11]​. The pain resulted in the patient being bedridden for extended periods of time and the lack of mobility caused a worsening in the patient’s mental health. The use of pain-related terminology in conversation, such as the name of a support group containing the word ‘burning’, or a visual representation, resulted in a sharp increase in pain experienced and often provoked a PTSD response. The patient had been offered a range of prescription and over-the-counter medications to alleviate her pain. Oral prescription medications included gabapentin and ketamine, but these caused side effects, such as tachycardia and arrhythmia, followed by breakthrough pain. The patient was selected to participate in an NHS trial with medical cannabis, which has been cited as a possible treatment for chronic pain disorders, but treatment was discontinued after one week owing to lack of tolerance to the medical cannabis​[12]​.

Treatment with transdermal unlicensed medication

In this case presentation, the treatment of CRPS is particularly challenging. The patient attempted various oral prescription medication regimes, including gabapentin and ketamine, and a short course of medical cannabis through an NHS trial. These medication regimes were used to mitigate the pain but none were deemed successful, and the side effects were intolerable. Alternative medications were considered, and the transdermal route of administration was identified as a valid option. Topical medications are designed to deliver the active pharmaceutical ingredients (APIs) directly to the skin; transdermal, permeation-enhancing medications are also applied topically but are designed to penetrate through the skin for systemic delivery​[13]​. As opposed to oral medications, the transdermal, permeation-enhancing medications bypass the gastrointestinal tract and first-pass metabolism​[13]​. As a result, the side effects commonly experienced with oral medications indicated in CRPS may be avoided​[4]​.

Transdermal, permeation-enhancing unlicensed medications are patient-specific and customisable to include different drug types, in various dosage strengths, that are delivered simultaneously in one application. As such, transdermal medications provide a way to reduce treatment complexity and pill burden, potentially improving patient compliance to treatment​[13]​. In addition, combination drug therapy may improve clinical outcomes by means of additive or synergistic properties from APIs with different mechanisms of action​[13,14]​. In light of these potential advantages, a customised, transdermal, permeation-enhancing, unlicensed medication was prescribed by the physician: ketamine hydrochloride 10% and amitriptyline 5% in a permeation-enhancing base (see Table 1). A specials company in the UK was contacted and the pharmacist confirmed that the required formulation could be manufactured for this individual patient. Topically applied unlicensed medications may be customised to include a permeation-enhancing base and APIs in variable concentrations to meet the individual patient needs. Clinical evidence and in vitro studies have validated the use of permeation-enhancing bases in pain management​[15–22]​.

The patient applied the transdermal medication to the affected area four times per day, prior to physiotherapy sessions. It was well tolerated, allowing greater compliance to treatment regimen compared with the previous oral medications. This was the only medication used by the patient to treat her CRPS at the time. Application directly to the affected site (i.e. knee) allowed for delivery of ketamine and amitriptyline into and through the epidermal and dermal layers of the skin, leading to high drug concentrations at the target site, while maintaining low systemic drug levels and thus decreased systemic side effects. The enhanced skin permeation enables topical medications to include APIs in higher concentrations than would otherwise be prescribed orally, potentially resulting in increased efficacy without compromising the safety of the medications​[23]​.

Outcome and follow-up

The patient completed a validated, neuropathic pain-specific questionnaire before and after treatment with the unlicensed medication to measure the treatment outcomes. The Neuropathic Pain Symptom Inventory (NPSI) was used to give information comparable to that provided by quantitative evaluation of pain symptoms​[24]​. The NPSI is a self-administered, easy to use questionnaire comprising 12 questions. On a scale from 0 (none at all) to 10 (worst imaginable), patients are invited to rate their spontaneous pain (burning, squeezing and pressure), paroxysmal pain (electric shock and stabbing sensations), evoked pain (brushing, pressure and contact), as well as abnormal sensations in the painful area (pins, needles and tingling). Two additional questions evaluate the duration of spontaneous pain and the frequency of pain attacks over the previous 24-hour period (see Table 2). Scoring is based on average ratings for 5 subscores (superficial, burning spontaneous pain; deep, pressing spontaneous pain; paroxysmal pain; evoked pain; and paresthesia/dysesthesia). The sub-scores were recorded on a scale of 0 to 10. A total intensity score per 100 is calculated by collating the scores from various combinations of questions​[24]​.

Prior to starting treatment with the unlicensed medication, the patient reported a very high total pain intensity score of 96 per 100. All pain subscores were rated as worst imaginable (score 10), with the exception of deep, pressing spontaneous pain and paresthesia/dysesthesia, which were rated 9 per 10. Over the previous 24-hour period, the patient reported her spontaneous pain as ‘permanently’ present with ‘more than 20’ pain attacks, which are the worst possible ratings for these two questions. To complement these responses, the patient added that a score of 10 would be triggered by the subtle air movement across her skin and any noise stimuli higher than soft sounds.

Owing to the COVID-19 pandemic and lockdowns, it took ten months for the post-treatment questionnaire to be carried out. At this point in treatment, the patient reported a significant decrease in ratings and therefore a considerable improvement of her CRPS. All pain subscores were below 5 per 10, with a rating of 0 for paresthesia/dysesthesia and 1 for deep, pressing spontaneous pain. The superficial, burning spontaneous pain and paroxysmal pain presented the highest average ratings of all subscores, with the patient explaining that this pain was triggered by psychologic stress only. The patient previously experienced severe pain and, as a result, the thought of it would trigger the onset of pain. The total pain intensity score decreased from 96 to 11.5 per 100. Over the previous 24-hour period, the patient’s experience of spontaneous pain changed from ‘permanently’ to ‘between 1 and 3 hours’, and the number of pain attacks decreased from ‘more than 20’ to ‘between 1 and 5’ pain attacks, as displayed in Table 2. The complementary responses for pain evoked by air movement and noise stimuli also decreased from a score 10 to 2. Throughout treatment, no side effects were reported. The patient noted that, initially, the pain relief lasted only around 30 minutes post-application. With the ongoing use, the pain relief lasted between applications, apart from when evoked by specific stimuli. According to the patient, the ongoing use of the unlicensed medication appears to be effecting lasting changes to her CRPS. The pain relief experienced allowed the patient to participate in physiotherapy and, as a result, she regained full range of movement and release of contracture in the region of her right knee.


To date, no medications have been licensed in the UK to specifically treat CRPS. Physicians may prescribe a commercial medication for unlicensed use or, alternatively, prescribe an unlicensed medication instead. Different classes of drugs are well documented and traditionally used in CRPS, including anaesthetics (e.g. ketamine), anti-inflammatory drugs (e.g. ibuprofen and prednisolone), anticonvulsants (e.g. gabapentin and pregabalin) and antidepressants (amitriptyline and nortriptyline)​[2,25,26]​. Gabapentin is one of the most prescribed oral medications for CRPS treatment. It is an anticonvulsant drug indicated in epilepsy, which has been found to be useful for treating neuropathic pain​[2]​. Although the mechanism of action is not fully understood, it is believed that gabapentin interferes with the voltage-dependent calcium ion channels and interrupts the series of actions that lead to neuropathic pain​[27]​. Oral ketamine is usually reserved for severe, intractable pain, as it is a potent anaesthetic that blocks activation of nerve cell receptors, thereby decreasing pain. If all interventions fail to alleviate symptoms, ketamine may also be given intravenously in outpatient clinics on a regular basis and titrated doses​[25]​. However, these oral and IV pharmacological treatments are not always well tolerated, owing to the frequency and severity of side effects, which can include anxiety, nausea, confusion and sleep disorders, depending on the drugs used​[28]​.

There is increased interest in topically applied drugs for the treatment of neuropathic pain owing to the potential of reduced side effects and increased patient compliance. Furthermore, topically applied drugs may also help healthcare providers effectively treat their patients, while avoiding the use of addictive oral opioid drugs​[13]​. Topical ketamine and amitriptyline are a promising combination and some studies have shown its efficacy in clinical practice​[29,30]​. A case report of a CRPS-1 patient, refractory to conventional pharmacological treatment, showed that topical treatment with ketamine 10% and amitriptyline 5%, combined with a permeation-enhancing agent, was efficacious and safe, with no reported side effects. Validated questionnaires were also used in this study to evaluate patient outcomes. Following one month of treatment, the patient reported a decrease in pain superior to 50% and a few months later the pain was virtually gone​[4]​.


CRPS is a debilitating, chronic neuropathic pain condition that requires a multidisciplinary approach to treatment. This article discussed a CRPS-1 patient with severe intractable pain, refractory to conventional pharmacological treatment. The patient was prescribed a transdermal unlicensed medication that included ketamine 10% and amitriptyline 5% in a permeation-enhancing base. Before treatment, the patient reported a very high total pain intensity score of 96 per 100, according to the NPSI. Following treatment, the patient had a decrease in pain, with no unwanted side effects, and a considerable improvement in her CRPS. As such, topical ketamine and amitriptyline is a promising combination in pain management when incorporated in a permeation-enhancing base. Unlicensed medications may be customised to meet the individual needs of patients and are therefore a good alternative in current therapeutics.

Key points

  • Complex regional pain syndrome is a debilitating condition that requires a multidisciplinary approach to treatment;
  • Pain management in CRPS is a challenging endeavour owing to the complexities associated with neuropathic pain;
  • Conventional pharmacological treatments, such as gabapentin and other oral prescription medications, do not always provide adequate pain relief and may cause unwanted side effects;
  • Pharmacists play an important role in patient-centred care, and may propose alternative pharmacotherapies to help reduce pain, increase mobility and improve the patient’s overall health-related quality of life in CRPS;
  • Unlicensed medications provide an alternative to commercially available medications and may be customised to meet the individual needs of patients;
  • Transdermal, permeation-enhancing medications are applied topically for a systemic delivery of active pharmaceutical ingredients, and can potentially reduce side effects, improve treatment compliance and maximise therapeutic effects;
  • A transdermal unlicensed medication, including ketamine hydrochloride 10% and amitriptyline 5% in a permeation-enhancing base, has proven effective in CRPS by providing optimal pain relief.

Declaration of interest:

The authors are employees of PCCA who manufacture the permeation-enhancing base referred to in this article.

  1. 1
    Eldufani J, Elahmer N, Blaise G. A medical mystery of complex regional pain syndrome. Heliyon. 2020;6:e03329. doi:10.1016/j.heliyon.2020.e03329
  2. 2
    Overview: Complex regional pain syndrome. NHS. 2022. (accessed Nov 2022).
  3. 3
    Sandroni P, Benrud-Larson LM, McClelland RL, et al. Complex regional pain syndrome type I: incidence and prevalence in Olmsted county, a population-based study. Pain. 2003;103:199–207. doi:10.1016/s0304-3959(03)00065-4
  4. 4
    Goebel A, Barker C, Turner-Stokes L. Complex regional pain syndrome in adults: UK guidelines for diagnosis, referral and management in primary and secondary care. Royal College of Physicians. 2018. (accessed Nov 2022).
  5. 5
    Kopsky DJ, Keppel Hesselink JM. Multimodal Stepped Care Approach Involving Topical Analgesics for Severe Intractable Neuropathic Pain in CRPS Type 1: A Case Report. Case Reports in Medicine. 2011;2011:1–4. doi:10.1155/2011/319750
  6. 6
    Taylor S-S, Noor N, Urits I, et al. Correction to: Complex Regional Pain Syndrome: A Comprehensive Review. Pain Ther. 2021;10:893–4. doi:10.1007/s40122-021-00291-8
  7. 7
    de Mos M, de Bruijn AGJ, Huygen FJPM, et al. The incidence of complex regional pain syndrome: A population-based study. Pain. 2007;129:12–20. doi:10.1016/j.pain.2006.09.008
  8. 8
    Fayaz A, Croft P, Langford RM, et al. Prevalence of chronic pain in the UK: a systematic review and meta-analysis of population studies. BMJ Open. 2016;6:e010364. doi:10.1136/bmjopen-2015-010364
  9. 9
    Torta R, Ieraci V, Zizzi F. A Review of the Emotional Aspects of Neuropathic Pain: From Comorbidity to Co-Pathogenesis. Pain Ther. 2017;6:11–7. doi:10.1007/s40122-017-0088-z
  10. 10
    Murphy L, Ng K, Isaac P, et al. The Role of the Pharmacist in the Care of Patients with Chronic Pain. IPRP. 2021;Volume 10:33–41. doi:10.2147/iprp.s248699
  11. 11
    Shim H, Rose J, Halle S, et al. Complex regional pain syndrome: a narrative review for the practising clinician. British Journal of Anaesthesia. 2019;123:e424–33. doi:10.1016/j.bja.2019.03.030
  12. 12
    Mücke M, Phillips T, Radbruch L, et al. Cannabis-based medicines for chronic neuropathic pain in adults. Cochrane Database of Systematic Reviews. 2018;2020. doi:10.1002/14651858.cd012182.pub2
  13. 13
    Bucher, PharmD CV, Day, PharmD AJ, Carvalho, PhD M. The role of transdermal compounding in opioid safety. J of Opioid Management. 2018;14:17. doi:10.5055/jom.2018.0425
  14. 14
    Zimmermann GR, Lehár J, Keith CT. Multi-target therapeutics: when the whole is greater than the sum of the parts. Drug Discovery Today. 2007;12:34–42. doi:10.1016/j.drudis.2006.11.008
  15. 15
    Bassani A, Banov D, Lehman P. Evaluation of the percutaneous absorption of promethazine hydrochloride, in vitro, using the human ex vivo skin model. Int J Pharm Compd 2008;12:270–3.
  16. 16
    Bassani AS, Banov D, Phan H. Characterization of the Percutaneous Absorption of Ketoprofen Using the Franz Skin Finite Dose Model. Postgraduate Medicine. 2016;128:262–7. doi:10.1080/00325481.2016.1144448
  17. 17
    Bassani AS, Banov D. Evaluation of the Percutaneous Absorption of Ketamine HCl, Gabapentin, Clonidine HCl, and Baclofen, in Compounded Transdermal Pain Formulations, Using the Franz Finite Dose Model. Pain Medicine. 2016;17:230–8. doi:10.1111/pme.12899
  18. 18
    Shakshuki A, Agu R. Compounded Topical Gabapentin for Neuropathic Pain: Does Choice of Base Affect Efficacy? Int J Pharm Compd 2019;23:496–503.
  19. 19
    Alexander K, Wynn T. Transdermal gel in the treatment of postoperative pain. Int J Pharm Compd 2007;11:181–4.
  20. 20
    Brown S, Erickson B, Muller G, et al. Compounded analgesic therapy for disorders of movement: arthritis, neuropathic pain, and postpolio syndrome. Int J Pharm Compd 2010;14:182–92.
  21. 21
    Christiansen J. Unique challenges in compounding: managing severe musculoskeletal pain in a recovered substance abuser. Int J Pharm Compd 2010;14:310–4.
  22. 22
    Marshall R, Vidaurri V, Boomsma D, et al. Case reports: compounding to relieve arthritis pain. Int J Pharm Compd 2008;12:498–504.
  23. 23
    Jones N. Complex Regional Pain Syndrome. Chester, Cheshire: 2021.
  24. 24
    Bouhassira D, Attal N, Fermanian J, et al. Development and validation of the Neuropathic Pain Symptom Inventory. Pain. 2004;108:248–57. doi:10.1016/j.pain.2003.12.024
  25. 25
    When Nothing Seems to Help Your CRPS, Ketamine Pain Treatments May Bring Relief. Cleveland Clinic. 2019. (accessed Nov 2022).
  26. 26
    Kwak SG, Choo YJ, Chang MC. Effectiveness of prednisolone in complex regional pain syndrome treatment: A systematic narrative review. Pain Practice. 2021;22:381–90. doi:10.1111/papr.13090
  27. 27
    Rose MA, Kam PCA. Gabapentin: pharmacology and its use in pain management. Anaesthesia. 2002;57:451–62. doi:10.1046/j.0003-2409.2001.02399.x
  28. 28
    British National Formulary 81. London: : Pharmaceutical Press 2021.
  29. 29
    Lynch M, Clark A, Sawynok J, et al. Topical amitriptyline and ketamine in neuropathic pain syndromes: an open-label study. J Pain 2005;6:644–9. doi:10.1016/j.jpain.2005.04.008
  30. 30
    Mercadante S. Topical amitriptyline and ketamine for the treatment of neuropathic pain. Expert Review of Neurotherapeutics. 2015;15:1249–53. doi:10.1586/14737175.2015.1101347
Last updated
The Pharmaceutical Journal, PJ, November 2022, Vol 309, No 7967;309(7967)::DOI:10.1211/PJ.2022.1.163445


  • Nicola Phillimore

    The declaration of interest is so important that I would have liked to see it at the start of the article.
    How impartial is this piece?

    • Alex Clabburn

      Dear Nicola. Many thanks indeed for your comment. I am the Senior Editor for Learning and Research at the PJ. I will write to you directly with a fuller response via email but wanted to assure you that the article went through our full editorial checks and was closely assessed before publication and that we treat questions around clinical validity and impartiality very seriously.

    • Linda Jean

      Dear Nicola,
      On behalf of all authors, I would like to thank you for bringing up such a valuable point. This case study was presented to us while the treatment was ongoing. The authors did not interfere in the treatment nor in the feedback provided. The patient and the caregiver signed a consent form provided by the PJ. For further discussion, please contact the corresponding author at: or

  • Derek Prater

    A good point raised by Nicola Phillimore, although the declaration of interest by a manufacturer would not necessarily impact on the findings or quality of a piece of research or a clinical observation or case study.

    However, in this instance I have concerns that the case study only represents a single case, has no control such as physiotherapy alone or physiotherapy with just the permeation-enhancing base, and the time delay of 10 months between pre-treatment and post-treatment neuropathic pain questionnaires in a condition which is likely to fluctuate over time. Those confounding factors make it impossible to draw any valid conclusions about the effect of the treatment.

    Whilst the report is an interesting single patient observation, the publication as a CPD and learning article "case study" raises serious questions about the rigour and validity of the PJ editorial checks.

    • Linda Jean

      Dear Derek,
      On behalf of all authors, I would like to thank you for taking your time to provide feedback on our case study. CPRS is a complex condition and patients often struggle to manage their symptoms. This individual patient had a remarkable improvement in her condition, and we believe that this treatment option may be a benefit to other patients suffering from the same condition. Patient advised the physiotherapy sessions were made increasingly easier during the treatment period.
      For further discussion, please contact the corresponding author at: or

  • Alex Clabburn

    Please allow me to introduce myself as the Senior Editor for Research and Learning at the Pharmaceutical Journal. First of all, thank you for taking the time to submit comments and raise these questions with us. We very much welcome constructive discussion and scientific critique of our publishing and the opportunity it provides for improved accuracy and better insight for our readers.

    In this instance we have shared your comments with the authors of the article and encouraged them to submit a written response to the specific questions you have raised. We accept that due to the real-world nature of the case presentation there were limitations that the reader needs to consider alongside the information provided, but we remain of the view that the article represents an interesting learning opportunity for our audience. As a case-presentation, we would also expect readers to appreciate that it represents a single data point drawn from clinical practice, and to factor this into their assessment of whether any conclusions can or should be drawn about this specific treatment strategy.

    Having reflected on the discussion that the article has generated, we acknowledge that there are improvements that we can make to the way we present case-based articles of this type, in particular around how learning points are communicated, the limitations of the case study as a source of evidence and the need for the reader to critique appropriately. We have initiated a review of our relevant editorial processes and author guidelines and will implement these improvements for all case presentations subsequently published.

    Thank you again for your comments.
